The Square LED Module is an efficient and compact lighting solution designed for a variety of applications, including signage, backlighting, and architectural lighting. Its square design allows for easy installation in confined spaces, while its energy-efficient LED technology ensures long-lasting performance with minimal power consumption. This versatile module offers uniform light distribution, making it ideal for both indoor and outdoor use.
· Input Voltage: DC 24V
· Power Consumption: 4W per module (depending on model)
· LED Type: SMD 2835 (model-dependent)
· Luminous Flux: 120 - 250 lumens per module
· Beam Angle: 120°
· Color Temperature : 3000K / 4000K / 6000K /10000K
· Dimming: 0-100% dimming capability (compatible with dimmable drivers)
· Operating Temperature: -20°C to 50°C (-4°F to 122°F)
· Lifespan: 50,000 hours
· Ingress Protection Rating:
o IP20 (for indoor use)
o IP65 (for outdoor use)
· Certification: CE, RoHS
