RGBCW Square LED Module

Product Overview:

The RGBCW Square LED Module is a highly versatile lighting solution designed to provide full-color illumination and adjustable white light (RGB + Cool White + Warm White). It is suitable for various lighting applications, including indoor and outdoor signage, architectural lighting, and retail displays. The square design makes it easy to integrate into both new and retrofit projects, offering bright, uniform lighting with flexible color control.

Technical Specifications:

· Input Voltage: DC 12V / 24V (depending on model)

· Power Consumption: 4W / 6W / 9W per module (model-specific)

· LED Type: RGBCW (SMD 5050 + 2835)

· Luminous Flux: 500 - 900 lumens per module

· Beam Angle: 120°

· Color Temperature (White):

· Warm White: 2700K-3000K

· Cool White: 5000K-6500K

· Color Options: Full RGB spectrum + adjustable white (Cool White & Warm White)

· Control Method: DMX, RF, or Wi-Fi (controller-dependent)

· Dimming: 0-100% brightness adjustment

· Operating Temperature: -20°C to 50°C (-4°F to 122°F)

· Lifespan: 50,000 hours

· Ingress Protection Rating: IP65 (waterproof, for outdoor use)

· Certification: CE, RoHS
